Features
- Highly precise cutting achieved with harmonization of the fiber laser, accurate CNC platform and advanced motion controlled software.
- Minimum heat effected zone
- Computer vision assisted tube centering facility
- Full digital control of all cutting process parameters
- Automatic tube feeding mechanism eometry errors in tight profiles
- Suitable for dry as well as wet cutting
- Velocity profiling helps to minimize gg process.
- Machine is constructed around solid granite base and highly rigid frame structure for stable results.
- One click cutting program generation from "Cagila" software
- Laser : 100 Watt fiber
- Wavelength : 1090 ±5 nm
- Tube size : up to 7.9 mm (for dry cutting), up to 3.0 mm (for wet cutting)
- Axis travel : 100 mm
- Accuracy : + 2 µm (+ 0.5 µm available as option)
- Dimensions : 1200 (L) x 700 (W) x 1355 (H) (Laser cutting machine)
- 745 (L) x 700 (W) x 775 (H) (Control station)
- Weight: 500 kgs. (Laser cutting machine), 125 kgs. (Control station)
- Power supply : 230 VAC 50 Hz or 110 VAC 60Hz
- Power consumption : 1500 Watts
